60K Intensifier Seal Ring

Tough Hytrel® support ring that sits directly behind the PTFE dynamic seal in Flow’s 60k rod pack. It prevents the soft seal from extruding into the high-pressure gap during stroke reversals,

Related Products:

• Dynamic Seal 5⁄16 ID 60 KSI (011051-1) — primary PTFE seal this back-up ring supports.
• Rod Seal Nitrile 5⁄16 ID × 9⁄16 OD 1⁄8 in (A-00720-31)
• Seal Carrier Assembly 60 KSI (013933-1)
• 60 K Intensifier End Cap (049887-1)
• HyPlex Minor Maintenance Kit (712101-1)

Service tip: install the back-up ring with a fresh dynamic seal, lightly oil the plunger, and torque the carrier to spec.
