60K Paser® ECL Plus Nozzle Body

The main structural housing for the ECL Plus cutting-head stack on Flow 60,000 psi abrasive waterjet systems. It supports alignment between the orifice, mixing chamber, collet, nozzle nut, and mixing tube so the high-pressure stream remains centered through the abrasive mixing path. A worn or damaged nozzle body can contribute to poor abrasive draw, inconsistent kerf quality, premature mixing tube wear, or leakage at the cutting head assembly.

Related products:

• ECL Plus Mixing Chamber Assembly (017364-1) — seats inside the ECL Plus nozzle body and supports stable abrasive entrainment.
• Paser® ECL and Paser® 4 Standard Mixing Tube (014214-xx-xx) — focuses the abrasive jet after it exits the mixing chamber.
• Precision Collet .281 to .242 Inch (A-23161-8) — locks the mixing tube in position to maintain repeatable alignment.
• Knurled Nozzle Nut 60K/90K (711589-1) — secures the nozzle body stack and helps prevent component movement during cutting.
• Paser® 4 60K Diamond Orifice (015849-xx) — forms the high-pressure waterjet before abrasive mixing in compatible 60K cutting-head assemblies.

Service tip: When replacing the nozzle body, inspect the chamber bore, orifice seat, mixing tube, collet, nut threads, and all sealing surfaces as a complete stack. Even small alignment errors in the cutting head can reduce abrasive draw, increase taper, and shorten the life of new wear parts.
