Pump Parts: Seals/Rings

Flow Parts

1/4" ID Dynamic Seal Plunger

1/4" ID Dynamic Seal Plunger

006747-1

The primary high pressure seal in Flow’s 40k psi Husky intensifier rod packs. Tough HDS White PTFE flexes under load to hug the ¼ inch ceramic plunger, holding a bubble tight seal.

Related Products:

  • Direct Drive Seal Carrier (013517-1) — precision pocket that houses the dynamic seal.
  • Direct Drive Seal Carrier Back Up Ring (008612-1) — rigid ring that supports the HDS seal against extrusion.
  • Rod Seal Nitrile 5⁄16 ID × 9⁄16 OD (A-00720-31) — installs behind the dynamic seal to keep oil out of the water end.
  • U-Cup Seal ¾ in ID × 1 in OD (A-10654) — completes the three seal stack in the Husky rod-pack.
  • Husky 40K Minor Maintenance Kit (406017)

Service tip: always fit a fresh back up ring and lightly oil the plunger when installing seal 006747-1. Replace at the first hint of rod pack weepage to keep the intensifier delivering full rated pressure.
